00100-04 | WPR, Hose Fitting (010646)

The "00100-04" hydraulic hose ferrule is designed for use with SAE 100R1A or DIN 20022 1ST hoses, specifically for the 1/4 inch (Dash size -04) hose size. This ferrule ensures a secure and leak-proof connection between the hose and its fitting, which is essential for maintaining the integrity of hydraulic systems.

Specifications:

• Hose Compatibility: SAE 100R1A / DIN 20022 1ST
• Hose Size: 1/4 inch (Dash size -04)
• Material: Carbon steel
• Surface Treatment: Zinc plating (CR3+) for corrosion resistance
• Dimensions:
  • Inner Diameter (D): Approximately 19 mm
  • Length (L): Approximately 30 mm

Applications:

The 00100-04 ferrule is suitable for various hydraulic applications, including:

• Industrial Machinery: Ensures secure hose connections in manufacturing equipment.
• Construction Equipment: Provides reliable performance in excavators, loaders, and other heavy machinery.
• Agricultural Implements: Maintains leak-proof connections in tractors and harvesters.
• Automotive Systems: Supports hydraulic functions in vehicles, such as braking and steering systems.

Installation:

This ferrule is designed for skive applications, meaning the outer layer of the hose is removed before crimping. Proper installation involves crimping the ferrule onto the hose and fitting assembly using a compatible crimping machine, ensuring a tight and leak-proof connection.
